The Motor Actuator Replacement Model ML8ML8-205B1 motor applies to replace Okin jldq12.157.333k and Limoss 450917. Just application in electric sofa. massage chair and seat bed. Check Label and also troubleshoot the switch/remote or power supply before ordering a motor.
-
Mulin Recliner Motor Actuator Replacement Model ML8 ML8-205B1 made by Mulin
-
Mulin ML8-205B1 motor applies to replace Okin jldq12.157.333k and Limoss 450917
-
2 Pin Flat Round Power Transformer Connection and 5 Pin Hand Control Plug Connection
-
Stroke: 333mm/13.11inches. Minimum install dimension: 157mm/6.18inches
- Just application in electric sofa. massage chair and seat bed. Check Label and also troubleshoot the switch/remote or power supply before ordering a motor
Technical data:
Model:ML8 ML8-205B1
Stroke: 333mm/13.11inches
Minimum install dimension: 157mm/6.18inches
Max. Load: 800N
Speed: 36mm/s
Input:DC 28V 1.5A
Interuptime: 0.5min/4min
Specifications
| Brand | Mulin |
| Color | Black |
| Material | Metal |
| Assembled Product Weight | 5.09 lb |
| Seat Depth | 0 in |
| Manufacturer | Mulin |
| Model | ML8-205B1 |
| Assembled Product Dimensions (L x W x H) | 24.60 x 6.70 x 3.80 Inches |
